The 512 SIM box equipment have 512 SIM card slots, each slot associated with a separate SIM card. These SIM cards can be from various mobile carriers. If you are looking for 512 SIM Box device, please contact us.
Special Features:
512 Channels
Web GUI: Firefox/Chrome /IE/Opera
NAT Traversal and Firewall
Hot Swap of SIM Cards without Powering Off
QoS support
Remote Manage of SIM Cards
Multi-language Support: Chinese and English
Dynamic Allocation of SIM Cards
Protect SIM Cards from Blocking
HTTP/TFTP Upgrade
Technical data
| Model | SK SIMPOOL512 |
| Number of Sim | 512 |
| Network Protocols | DHCP / PPPoE / VPN(pptp) |
| NTP | |
| Telnet / HTTP / FTP / TFTP | |
| Number of Ports | 1 WAN 10 / 100Base - T ethernet (RJ - 45 connector) |
| 1 Console(USB) | |
| LEDs | 1 Power and 256 groups of card online and running status indicator |
| Power Supply | 100 - 240V AC, 50 - 60 Hz IN, 12V / 3A OUT |
| Operating Environment | Operating temperature: 0 - 50ºC |
| Operating humidity: 10 – 90% RH | |
| Dimension (L x W x H) | 530 * 305 * 90mm |
| Weight | 8kg |
| Warranty | 12 Months |
Advantages of a 512 SIM Box Device:
High Capacity: With 512 SIM card slots, the device offers the ability to manage a significant number of concurrent channels for voice and SMS communication.
Concurrent Connectivity: Enables simultaneous connections for handling multiple calls or messages, potentially providing scalability for large-scale communication services.
VoIP Integration: Integration with VoIP allows for cost-effective routing of calls over the internet, potentially reducing communication costs.
Remote Management: Remote management capabilities facilitate easy configuration, monitoring, and management of the device, providing flexibility and control.
Load Balancing: The device may include load balancing features to optimize the distribution of traffic across SIM cards, ensuring efficient utilization.
The application of a 512 SIM Box device involves managing a large number of SIM cards simultaneously to facilitate cost-effective voice and SMS communication. Typically used in telecommunication setups, the device routes calls and messages through multiple SIM cards, often leveraging Voice over Internet Protocol (VoIP) for connectivity. This allows operators to handle numerous channels concurrently, making it suitable for bulk messaging, call termination, or other services.
