FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
  • FXS series voip gateway
FXS series voip gateway FXS series voip gateway FXS series voip gateway FXS series voip gateway FXS series voip gateway FXS series voip gateway FXS series voip gateway FXS series voip gateway

FXS series voip gateway

     FXS VoIP Gateway



    VoIP Analog Gateways with 2,4,16,24,32 48, 72, 96 FXS/FXO ports, support SIP and MGCP, also IMS specs;



    Nice VoIP access gateways for IP PBX and IP Centrex application;



    Supports  TR069/SNMP, Auto Provision, WEB GUI management;

    T.38 and T.30 FAX



    Compatible with the popular IP PBX like Asterisk, FreeSwitch, Elastix, 3CX, Microsoft Lync, Cisco call manager



    Support Routing table, and PBX functions;



    Up to 96 FXS VoIP Gateway, Asterisk VoIP Gateway


  • Description
  • Features
  • Application
  • Remarks

Comprehensive Feature Set
As an intelligent gateway running on embedded Linux operating system, WSS120G is compatible with many highlighted features such as call forward, call transfer, 3-way calling, caller ID, DND, color ringback, call forking, automatic routing, Digitmap and much more to provide a complete and highly reliable VoIP solution applicable to most scenarios.



Carrier-class Reliability
Supports high availability configuration including SIP registration failover, load balance as well as PSTN failover, with reliable 1+1 redundancy of Gigabit Ethernet ports and power supplies (optional), ensuring no loss of service and minimizing the communications downtime.


Key Features:

- SIP/MGCP protocols
- 500 routing and number manipulation rules
- Fax over IP using T.38 version 3 fax relay with V.34 and automatic switching between voice/fax
- Hot-swappable FXS/FXO interface card
- Dual redundant Gigabit Ethernet ports
- Dual AC/DC power supplies
- PSTN failover
- Auto provisioning
- Remote access via Real Tone Cloud
- Management with Real Tone or third party Network Management System (TR-069, SNMP)
- Interoperability with popular SIP servers, such as Cisco CallManager, Broadsoft, Microsoft Skype for Business (Lync), Huawei IMS, and Asterisk/Elastix
- Class I lightning protection


CPU

1 GHz

Voice DSP module

200 MHz, 3 to 12 modules

RAM

256 MB,DDR3

FLASH

32 MB

H×W×D

85 × 440 × 300 mm

Weight (net)

6.32 kg maximum

Single/Dual AC

100 to 240 VAC, 50/60 Hz, 2A maximum

power supplies


Single/Dual DC

-36 to -72 VDC, 4A

power supplies




Power consumption

110 W



Mounting

Rack



Operating

Temperature: 0 to 40°C


Humidity: 10 to 90% RH (non-condensing)

Storage

Temperature: -40 to 70°C


Humidity: 5 to 90% RH (non-condensing)
